ELECTRICAL CHARACTERISTIC
Rated Operational Voltage (V AC)	Up to 600V
Frequency (Hz)	50 / 60Hz

PFC FEATURE
Total KVAR	Up to 1000KVAR > 1000KVAR Can Be Request
Switching Step	6, 9, 12 > 12 step Can Be Request

MECHANICAL CHARACTERISTIC
Form Segregation According to IEC 439-2	2B / 3B / 4B
Degree of Protection According to IEC 529	External IP54 / 41 Internal 2X
Surface Protection	Anti Rust Treatment / Epoxy Power Coating / Oven Baked
Standard Colours	RAL 7032 Other Colors Upon Request
Access	Front and Rear
Cable Entry	Top and Bottom
Ventilation	Mechanical Air Louvers

MATERIAL
Frame Structure Material	EG Sheet
Material Thickness : • Frame Structure Material	2.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Front Cover	2.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Side / Rear Cover	2.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Internal Separation	1.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Base	Robust C - Channel
• Protection Barrier	Polycarbonate Sheet 2.0mm
